Phoenix Gold ZR6004R - 600W 4-Channel Class-D Amplifier with Bass Remote

The ZR6004R is a powerful 600W 4-Channel Class-D Amplifier with a fantastic compact design suitable for even the smallest installs. Featuring massive power, the ZR6004R uses its high-grade connection terminal to ensure a clean crisp power delivery to all your components.

Step into the world of precision sound engineering with the ZR6004R, a compact yet mighty 600W 4-Channel Class-D Amplifier that defies expectations. Crafted to excel in the most confined installations, this amplifier, with a sleek, space-conscious design, promises a great audio experience.

With ratings of 4 x 150W at 2 ohms, 4 x 100W at 4 ohms, and an impressive 2 x 300W when bridged to 4 ohms, this amplifier showcases unparalleled versatility across various impedance levels.

This adaptability ensures it seamlessly integrates into diverse audio setups, from power-hungry configurations to more controlled environments.

Compact dimensions of 233.66 x 160 x 48.3mm underscore its suitability for the most space-restricted installations, ensuring it slips seamlessly into any setup without compromising its performance capabilities.

The ZR6004R doesn’t just amplify soundit refines it. With full-function 12dB filters spanning High Pass and Low Pass, extended to 5kHz, this amplifier offers meticulous control over frequencies, enabling users to sculpt the audio output precisely.

Including a Low-Level Differential Balanced Input further enhances compatibility and fidelity, ensuring an elevated listening experience.

Safety and reliability are paramount, and the ZR6004R is fortified with full circuit protection, guaranteeing sustained performance while safeguarding against electrical mishaps. Its fan-less design speaks volumes about its efficiency and durability, ensuring optimal performance without compromising silence or reliability.

The AutoStart function on High-Level Input further enhances convenience, seamlessly initiating operations upon detecting the input signal.

ZR6004R Product Specifications:
Class D
4 Channels
Frequency Response: 12Hz 22kHz
RMS Power Rating (1?): N/A
RMS Power Rating (2?): 4 x 175W
RMS Power Rating (4?): 4 x 105W 2 x 350W Bridged
Signal to Noise Ratio (SNR) (Full Power): -90dB
Total Harmonic Distortion (THD): <1%
Low Pass Filter (LPF): 50Hz 400Hz (12dB/Oct)
High Pass Filter (HPF): 50Hz 400Hz (12dB/Oct)
Subsonic: N/A
Bass Boost @ 45Hz: 0 +18dB
Crosstalk: -60dB
Input Sensitivity: 0.25V 9.8V
Fuses: 2 x 20A
Remote: Yes (Included)
High-level Input Via RCA: Yes
Auto Turn-on: Yes
Phase Control: N/A
Operating Voltage: 9-16Volt
Idle Current: 0.55A
Current Draw: (Max) 34A
Total Efficiency: (4?) 88%
Power Terminal: 20mm
Speaker Terminal: 4mm
Dimensions: (LxWxH) 254 x 160 x 48.3mm
Weight: 1.76 kg

ZR6004R Benefits:
ZR Amplifiers small size amplifiers with Class D Design
REAL POWER amplifier designed with the latest Class-D technology
Full function filters
Low and High-level input
Autostart on High-Level input
Balanced differential input design
High-grade terminals
High-grade aluminium chassis
Fanless design
ZR6004R Unique HP & LP function 12dB filter from 50-5kHz to accommodate Active filter for Midrange and Tweeter
Pair with Aftermarket HU and get bandpass-filter for active front system
Mono amps subsonic filter
Remote gain controller made clever
Short, Thermal, Overload Protection circuits
Min 10% power margin (1000W delivers over 1500W RMS in low load)
